Flexible Mesh Screen
Flexible Mesh Screen
Make Your Building Tell Stories! Extremely Flexible LED Mesh Screen-?Rollable; Save time and cost; High Transparent; IP67 Design & UV proof;Ultra Lightweight & Slim Mesh; Lower energy consumption.
Application: Indoor commercial display,large-scale building wall mesh screen, Plazas & City Landmarks display

Make Your Building Tell Stories! Extremely Flexible LED Mesh Screen

Make Your Building Tell Stories! Extremely Flexible LED Mesh Screen-:Rollable; Save time and cost; High Transparent; IP67 Design & UV proof;Ultra Lightweight & Slim Mesh; Lower energy consumption.

Application: Indoor commercial display,large-scale building wall mesh screen, Plazas & City Landmarks  display

Flexible Design

Ultra flexible design make it can be curved freely to achieve creative shapes like arch, circle, wave, Fully Customizable Media Facade, No limit for the mesh screen size. Any size is possible!


Sometimes, we need the tailor-made mesh solution to meet the architects’ design or fit for the special shape.can cover any size facade perfectly by adjusting pixel pitch freely. It can get the best solution to match the circumstances instantly!

Extremely Flexible LED Mesh, saves space and cost;
In a word, the flexibility feature makes it very easy to do the preparation job, installation, and maintenance.



Rollable

The Flexible LED Mesh Screen is rollable. Even 10 meters of length led mesh can be rolled into a small pillar. It doesn’t need much space to keep a big size mesh screen.

As a result, it saves much shipping cost and time when you move a big quantity of led video mesh panels from the manufacturer to your country, from the warehouse to the installation site.


High Transparency 70%~96% / High natural light Transmittance

People like to live inside the buildings with high light transmittance. Because sunlight makes peoples healthy and joyful.

Obviously, Mesh Screen’s high transparency mesh will not block natural daylight.

Second Skin

When switched off the mesh, the original building facade remains visible.

The mesh screen doesn’t visually influence the building facades, in contrast, its elegance enhances the appearance. Thanks to its high transparency even up to 95% for some models, the led mesh wall is warmly welcomed by architects, advertisers, and designers.

Black and Clear frame for options

You may need black frame to get a better contrast. On the stage, the black frame will integrated well with the backdrop.

On the building facade, sometimes, the clear frame might be a better option, especially over a glass wall. Choosing a suitable color for your frame is up to the final application.


Fast  Locks

Fast inter-panel locks make it quick and easy to set up and dismantle large-scaled screen, no tools required. In addition, the LED dot string is detachable, which can be taken off directly from the frame with little effort by hand from some certain angle

Easy + Minimum maintenance Costs

The led mesh has two parts including pixel strings and the holding frame. Only the led pixels has chance to be broken. for a giant screen in the upper air, even with the best quality, you need to concern about how to maintain.

Every individual LED pixel dot is changeable, no need to take out a whole string or dismantle any frame structure.The process could be done even when the mesh is working. You could get the result instantly without any delay, and there is no repeat painful job, like climbing up and down to turn on/off the power.

After-sale repair has the lowest cost.


Quick Installation

LED mesh screen with Quick hanging up by using the following two pieces of connector.

It’s known that time means money, especially when going to build more than a thousand square meters led facade screen.
No complex frame structure required
The mesh screen is supplied in rolls, completely preassembled and ready-to-go for installation.

And there is no complex frame required on the building facade to fix the huge mesh.

Ultra Lightweight & Slim Mesh

The flexible led mesh is ultra-lightweight and extremely-slim, around 15mm. The final weight depends on the LED resolution. For example, it is 3.5 kg/sqm for P50mm, and but only 2kg/sqm for P100mm.

Waterproof  Connectors

Head and tail of the panel, with waterproof connectors.


Day and Night viewing capability, Automatic brightness Adjustment

Outdoor Media Mesh facade can be viewable both in day and night.

When visible in extremely bright conditions, for example, facing direct sunlight, we choose the led mesh display with very high light intensity up to 2,500 Nits.

But when it’s getting dark, during dusk and night-time, you’d better lower brightness to prevent light pollution. For example, it has a bad influence on drivers’ eyes. So if only watch the led mesh display during night-time, a low brightness version led mesh is the best option. And it will be cheaper!

-Adjust the brightness Automatically

Thanks to the light sensor system, our media mesh can adjust its brightness automatically according to ambient lighting conditions.


Adopt High-grade LEDs, Gold-Wire SMD 5050 RGB LED

LED Mesh Screen adopted Broken-point Continuingly-transferring technology

In short, any middle pixel is broken, the left dots keep work well.

With this design, any dead pixel on the large-format led mesh screen will be not so obvious. Thus it leaves you time to maintain the mesh later, and save you the cost if you did maintenance for several dead pixels at one scheduled time

Durable and Sustainable – IP67 Design & UV proof

-Frost or Extreme weather resistance
The electronics and power supplies have a wide range of working temperatures between -30 °C ~ +60 °C.

And the plastic materials meet V0 high grade fire-proof and are durable in harsh environments.

Lower energy consumption
The flexible led mesh, of course, has much lower energy consumption than conventional billboards for the same area because it has a lower resolution.
