Everything You Need To Know About OBD, OBD II

If you purchased a car after 1996, it probably has an OBD-II port. But what is it for, and how do you diagnose errors with it?

OBD2 What Is the OBD-II Port and What Is It Used For?:

If you purchased a car after 1996, chances are it has an  OBDii (Onboard diagnostics II) port. Every car or truck on the road manufactured after 1996 is legally mandated to have one installed.

OBD-II is an onboard computer that monitors emissions, mileage, speed, and other data about your car. It’s connected to the Check Engine light, which illuminates when the computer detects a problem.

The OBD-II onboard computer features a 16-pin port under the driver’s side dash. It allows a mechanic or anyone else to read the error code using a special scan tool.



OBD-I vs. OBD-II

OBD Port

Before OBD-I, each manufacturer had its own set of standards for OBD, meaning that mechanics had to buy expensive scan tools for each plug type. OBD-I was first introduced in 1987 and started the standardization of onboard diagnostics. It had sensors that detected emissions and minimized them through emissions-controlling valves. However, it had many problems and shortfalls.

As a result, in 1996, car manufacturers started to equip cars and trucks with an OBD port. Every system is mostly the same, but there are slight variations. These are known as protocols and are specific to vehicle manufacturers.



There are five basic signal protocols:

  • SAE J1850 PWM: Pulse Width Modulation, used in Ford vehicles
  • SAE J1850 VPW: Variable Pulse Width used in General Motors vehicles
  • ISO9141-2: Used in all Chrysler and a variety of European or Asian vehicles
  • ISO14230-4 (KWP2000): Keyword Protocol, used in various American, European, and Japanese brands like Honda, Jeep, Land Rover, Subaru, Mazda, Nissan, and more.
  • ISO 15765 CAN: Controller Area Network, used on all vehicles manufactured after 2008

Pins 4 and 5 in all protocols are used for ground connections, and pin 16 is used for power from the car’s battery.

Once the computer senses a problem with the engine or any other component of the car it’s monitoring, it’ll trigger the Check Engine light.



How Does OBD-II Work?

Diagnostic Trouble Codes (DTC) are stored in the computer system. Codes can vary from one manufacturer to another. However, anyone with an OBD tool can connect to the OBD-II port and read the diagnostic trouble codes from the computer.

Any OBD-II scan tool can read the codes because of the standardized pinout. Scan tools can read from any of the protocols listed above. The standardized pinout is as follows.

OBD2 scanners can connect to these ports on your vehicles and identify the trouble code from any manufacturer that uses one of the OBD-II protocols.

  • Pin 1: Used by manufacturer
  • Pin 2: Used by SAE J1850 PWM and VPW
  • Pin 3: Used by manufacturer
  • Pin 4: Ground
  • Pin 5: Ground
  • Pin 6: Used by ISO 15765-4 CAN
  • Pin 7: The K-Line of ISO 9141-2 and ISO 14230-4
  • Pin 10: Used only by SAE J1850 PWM
  • Pin 14: Used by ISO 15765-4 CAN
  • Pin 15: The K-Line of ISO 9141-2 and ISO 14230-4
  • Pin 16: Power from the car battery

OBD-II scanners can connect to these ports and identify the trouble code from any manufacturer that uses one of the OBD-II protocols.

What Can Be Hooked Up to the OBD-II Port?

Traditionally, a mechanic would hook up a scan tool to the OBD-II port to read the DTC. Less expensive scanners would only provide a numeric code, which the mechanic would then look up from the manufacturer’s manual or service website. More costly scanners will provide text error codes.

However, in recent years, there have been more advanced tools available for regular drivers who don’t want to have to depend on a mechanic to find out what’s wrong with their car.

One example is OBD-II scanners. These can come in an array of configurations like wired and wireless. You can also find devices that connect to your smartphone or laptop and some with their own screen. Whatever you prefer, the choice is there.

Another option is GPS trackers. These can be hardwired into your vehicle, though they are commonly placed in the OBD port to give the device adequate power. These can be especially helpful in keeping track of loved ones or young drivers.
