There's just nothing like mastering electric wiring! As youngsters we marveled at the "magic" of electricity, but even now as adults, we nonetheless can't aid but stand in awe at its power. We may not know exactly how and why it works, but we do understand that it does. By following some basic wiring concepts, you may far more than just realize its power. You will have inside your arsenal the ability to harness that power and use it as you see match. I have covered safety in preceding articles so I will assume that you are aware of the potential dangers of electricity and tips on how to stay away from them. Get far more data about подключение электричества к участку
I will be going over some fundamental connection approaches that you can incorporate instantly within your personal home wiring. In theory, most home electric wiring is just extending wire from you most important breaker panel to each of the various outlets and lights about your house. So let's say you might have 20 20 amp breakers inside your primary panel and you happen to be already using 10. You need to draw power towards the new room you're inside the process of developing and you happen to be asking yourself tips on how to go about it. Now if there was only 1 outlet you necessary power for, this wouldn't involve any mid-way connections.
Forgive me if I'm wrong, but I'd say for many rooms you'd want at least 1 outlet and 1 light. And already right here you are going to be needing your connection. The tricky issue about lights is that you typically wish to attach a switch too - which makes the connection just a little additional complex. Once you get used for the notion it won't be so tricky. Within this write-up I'll only be going through the connection process, not the "what to connect to what". Don't forget to only connect towards the principal breaker immediately after Anything else has been attached and there are actually no naked wires. Before we start, you will be needing the following:
1. Crimper. This is to crimp 2 or additional copper wires collectively.
2. Wire stripper. For stripping the thin insulation off person cables.
3. Utility knife. Use this to slice away thick outer insulation.
4. Crimp connectors. You are going to be needing a generous load of those little guys. By the way, these are the tiny triangular shaped things at the ends of your connections around the diagram which you are going to be crimping 2 or extra cables with.
5. Electric tape. For taping connections with each other soon after crimping.
6. Nylon bands. These could be deemed an overkill, but I take safety seriously.
Ok, now that we've what we need to have, let's begin.
1. With your utility knife, strip away an acceptable amount of outer insulation, exposing the person "colored" cables inside.
2. Now together with your wire stripper, strip slightly far more than one crimp connector's length of insulation from every with the cables. The concept is usually to bare only what is vital and no much more.
3. Take your connectors and begin crimping them collectively together with your crimper tool. There are going to be varying connector sizes based on how numerous cables you're crimping collectively, so choose the appropriate sizes. Note that crimping properly is just as vital because the crimping act itself - guarantee that the connection is rock-solid and that there is certainly zero movement when you tug forcefully around the cables. You'll want to crimp the connector in numerous points to ensure maximum bond. You should not overlap cables in an "X" fashion when crimping, but must aim for any parallel connection.
4. Thoroughly tape all connections with electric tape.
5. Tighten bands around all finished connections and clip off excess. This ensures the electric tape doesn't come loose more than time - which CAN come about otherwise. Adding an further band around the conjoined cables 5 or so centimeters below the connection ensures the individual cables don't accidentally get "pulled" apart.
There you have your connection! Note that there are alternatives to crimping for example small connector boxes, but they're additional high-priced and not appropriate for outside use - rainwater gets trapped inside and may bring about shorting. In the event you do use these, make sure to stick only to indoor use and bend the connection upward so the "entrance" is facing down. The pros to these connectors is that they make connecting cables incredibly fast and very simple. Another essential point is evenly distributing your electric load for your individual breakers as this can save you money in your electric bill more than time.
