ONLINE DIGITAL REVERSE ENGINEERING SERVICE
Get your 3D Scans Converted into CAD files
More than 50 + Digital applications in one online platform
Any Large volume projects can be executed
Before you do it in-house try us once
Save on average 35% off your Scan to CAD project Cost.
Precise3DM Digital Reverse Engineering service helps customers to convert the complicated 3D Scan into CAD files that are editable, ready to manufacture, analyze, or be used for any other downstream applications. Utilize our team of highly skilled reverse engineers using cutting-edge software. Get cost-effective, per-part pricing instantly. Once you approve, our team will immediately get in touch with you and process your 3D Scan to CAD.
Why Precise3D?
India's largest team dedicated to Digital Reverse Engineering using professional software for Reverse Engineering reverse-engineering-service
Any 3D Scanner output can be developed/converted to CAD designs. reverse-engineering-service
Output can be delivered in any CAD software format such as SOLIDWORLS, ProE Catia on request, etc reverse-engineering-service
Even partial 3D Scans can be used to develop the 3D model. reverse-engineering-service
3D Scan groups, point clouds, .STL files are acceptable. reverse-engineering-service
Completed 5000+ projects reverse-engineering-service
More than a decade of reverse-engineering expertise.
IMPORT FILES
Your 3D Scanned file(.Stl) is imported into dedicated digital reverse engineering software
CHOOSE RIGHT MODELING TECHNIQUE
Based on your technical requirement the form you filled out during the RFQ, We apply the right Digital Reverse Engineering technique and convert your 3D Scans to CAD
EXPORT
CAD files are exported and sent to the client to receive feedback if there is any modifications or amendment over the Reverse engineered CAD
Design intent modeling refers to a designer’s specifications of how a part should appear and function. The concept of design intent modeling plays a significant role in reverse engineering, which is a process that works backward to take measurements from an as-built part and create a usable CAD model. This process involves measuring a physical object and reconstructing it as a 3D model to recover the design intent, a perfect regeneration of the original design in terms of simple analytical surfaces like planes, cylinders, etc., and freeform surfaces to produce a new reference CAD model. 3D scanners are generally the endorsed technology for extracting dimensional information and optimize the design to represent it as a point cloud or an automatic and instant mesh in the reverse engineering process.
Reverse Engineering obtains a combination of two feature model by hybrid modeling, from measured data to reconstruct the original
