Correct installation and wiring of automatic door operator
Automatic doors have been widely used in various smart home life, so how the automatic door operator is installed and wired? Automatic door operators are the control components of automatic doors, and automatic door operators have a direct role in managing the daily opening and closing operations of induction doors Influence. Let's take a look at the wiring instructions of the automatic door operator!
When installing the automatic sensor door controller, some precautions must be paid special attention to.
The automatic door human body detection part adopts the transmitting and receiving technology of the remote control of household appliances, which is not affected by the ambient light. The automatic door operator is a remote control device that uses radio signals to control various institutions in the distance. It is an intelligent multifunctional manual and wireless remote control dual-purpose electric door controller.
Commonly used automatic door operator systems are generally divided into two parts: transmitting and receiving. The following is a detailed explanation of the installation and wiring of the automatic door operator.
First, in order to ensure the normal use of the automatic door operator after installation, the installation of the automatic door operator must be installed by professionals in accordance with the requirements of the manual. At the same time, it should be connected correctly with reference to the wiring diagram attached to the product.
Second, the power cord and motor power cord used for the installation of the automatic door operator should be copper core sheathed cables with a wire diameter of not less than 1.5 mm2, and other control wires should be copper core cables with a conductor cross-section of not less than 0.5 mm2. The live wire of the power supply should be connected to the L end of the controller, and the neutral wire should be connected to the N end of the controller.
Third, it is better to use a Ф5×20mm/6A fast fuse for the internal fuse of the induction door controller. It is strictly forbidden to use the internal fuse as a direct short circuit. The probe of the automatic door operator is installed at an appropriate height outdoors, and the angle can be adjusted according to the actual situation.
Fourth, the installation position of the induction door controller should be selected according to the user's specific situation and hung on the wall without magnetic field interference, and the installation height should not be less than 1.2m from the ground. The cables drawn from the automatic door operator should be fixed along the wall and fixed firmly.
Fifth, after the installation of the automatic door operator is completed, all the installation work must be carefully checked one by one before the power is officially turned on, and the power can be turned on for trial operation after confirming that it is correct. The probe is installed at an appropriate height outdoors, and the angle can be adjusted.
When installing and wiring the automatic door operator, in addition to the items required by this regulation, other items shall comply with the relevant provisions of the electrical safety operation regulations. Non-professionals do not advocate wiring the induction door by themselves, and standardizing the device can ensure the safety of use and a lower failure rate.
The above is the wiring instructions of the automatic door operator. About how the automatic door operator is installed and wired, everyone must have a certain understanding. As the control component of the automatic door, the automatic door operator has a good intelligent judgment function and high reliability.
